Lifting clip, 1.1/2″
Lifting clip, 1.1/2″
Lifting clip, 1.1/2″. This accessory is used in the lifting set with a 1.1/2″ opening with an automatic locking system that allows the execution of the service without the risk of accidental detachment of the conductor. Made of aluminum alloy.
Models
Specification
Models
| Reference | Description |
| TM03070203 | Lifting clamp, 1.1/2″ without insulator |
| TM03070204 | Lifting clamp, 1.1/2″ with insulator |
Specification
| Reference | Insulator | Diameter (mm) | Length (mm) | Nominal working capacity (daN) | Approx. Weight | |
| Kg | lb | |||||
| TM03070203 | Without insulator | 64 | 310 | 454 | 1,30 | 2,87 |
| TM03070204 | With insulator | 65 | 310 | 454 | 1,75 | 3,86 |
