Made of fiberglass tube impregnated with epoxy resin and polyurethane foam core, it has double profile stringers, round steps with non-slip surface, backstrap with rubber coating, providing better fixation during the execution of services and mobile shoes for better use on uneven terrain.
This ladder is designed for assistance in interventions of energized networks of up to 500 kV.
All models have a workload of 567 daN.
Reference | Description |
PA0210112 | Double Stringer Extension Ladder, Ø 32 x 4020 x 7040 mm, 22 steps |
PA0210113 | Double Stringer Extension Ladder, Ø 32 x 4620 x 8240 mm, 26 steps |
PA0210058 | Double Stringer Extension Ladder, Ø 32 x 5220 x 9440 mm, 30 steps |
PA0210059 | Double Stringer Extension Ladder, Ø 32 x 6240 x 10760 mm, 34 steps |
PA0210060 | Double Stringer Extension Ladder, Ø 32 x 6840 x 11840 mm, 38 steps |
Reference | Diameter (mm) | Closed Length (mm) | Opened Length (mm) | Number of Steps | Approx. Weight (Kg) |
PA0210112 | 32 | 4.02 | 7.04 | 22 | 19,05 |
PA0210113 | 32 | 4.62 | 8.24 | 26 | 24,50 |
PA0210058 | 32 | 5.32 | 9.14 | 29 | 30,00 |
PA0210183 | 32 | 5.93 | 10.36 | 33 | 33,00 |
PA0210059 | 32 | 6.24 | 10.76 | 34 | 35,50 |
PA0210060 | 32 | 6.84 | 11.84 | 38 | 39,00 |
Reference | Description |
PA0210112 | Double Stringer Extension Ladder, Ø 32 x 4020 x 7040 mm, 22 steps |
PA0210113 | Double Stringer Extension Ladder, Ø 32 x 4620 x 8240 mm, 26 steps |
PA0210058 | Double Stringer Extension Ladder, Ø 32 x 5220 x 9440 mm, 30 steps |
PA0210059 | Double Stringer Extension Ladder, Ø 32 x 6240 x 10760 mm, 34 steps |
PA0210060 | Double Stringer Extension Ladder, Ø 32 x 6840 x 11840 mm, 38 steps |
Reference | Diameter (mm) | Closed Length (mm) | Opened Length (mm) | Number of Steps | Approx. Weight (Kg) |
PA0210112 | 32 | 4.02 | 7.04 | 22 | 19,05 |
PA0210113 | 32 | 4.62 | 8.24 | 26 | 24,50 |
PA0210058 | 32 | 5.32 | 9.14 | 29 | 30,00 |
PA0210183 | 32 | 5.93 | 10.36 | 33 | 33,00 |
PA0210059 | 32 | 6.24 | 10.76 | 34 | 35,50 |
PA0210060 | 32 | 6.84 | 11.84 | 38 | 39,00 |
