Wire tong
Wire tong
The wire tong can be used in numerous maintenance work in electrical network such as maintenance of crossarms, insulators, pole replacement, etc. It is used to move and holding energized conductors clear of working area.
Manufactured from fiberglass insulating tube impregnated with epoxy resin and polyurethane foam core, with varying diameter and length, it has in one edge aluminum alloy head with closure through torsion system (turning) and on the other edge a forged steel rotating eye.
All models have jaw with aperture variation that allows the fixation on conductors with diameter of 4,10 to 57,00 mm (0,16″ to 2,25″).
Reference
Specifications
Reference
| Reference | Description |
| PA0440085 | Wire tong, 38 x 1740 x 2160 mm |
| PA0440086 | Wire tong, 38 x 2200 x 2620 mm |
| PA0440149 | Wire tong, 38 x 2350 x 2770 mm |
| PA0440174 | Wire tong, 38 x 2600 x 3020 mm |
| PA0440087 | Wire tong, 38 x 2960 x 3380 mm |
| PA0440088 | Wire tong, 51 x 1700 x 2120 mm |
| PA0440089 | Wire tong, 51 x 2330 x 2750 mm |
| PA0440226 | Wire tong, 51 x 2400 x 2820 mm |
| PA0440090 | Wire tong, 51 x 2920 x 3340 mm |
| PA0440091 | Wire tong, 51 x 3530 x 3950 mm |
| PA0440229 | Wire tong, 64 x 1800 x 2220 mm |
| PA0440092 | Wire tong, 64 x 2290 x 2710 mm |
| PA0440093 | Wire tong, 64 x 2900 x 3320 mm |
| PA0440094 | Wire tong, 64 x 3210 x 3630 mm |
| PA0440175 | Wire tong, 64 x 3450 x 3870 mm |
| PA0440096 | Wire tong, 64 x 3510 x 3930 mm |
| PA0440097 | Wire tong, 64 x 4120 x 4540 mm |
| PA0440095 | Wire tong, 64 x 4730 x 5150 mm |
Specifications
| Reference | Dimensions | Working Load (daN) | Approx. Weight (Kg) | |
| Insulated Length (mm) | Overall Length (mm) | |||
| Ø 38 mm | ||||
| PA0440085 | 1740 | 2160 | 680 | 3.30 |
| PA0440086 | 2200 | 2620 | 680 | 4.17 |
| PA0440149 | 2350 | 2770 | 680 | 4.45 |
| PA0440174 | 2600 | 3020 | 680 | 4.93 |
| PA0440087 | 2960 | 3380 | 680 | 5.61 |
| Ø 51 mm | ||||
| PA0440088 | 1700 | 2120 | 907 | 4.60 |
| PA0440089 | 2330 | 2750 | 907 | 6.30 |
| PA0440226 | 2400 | 2820 | 907 | 6.49 |
| PA0440090 | 2920 | 3340 | 907 | 7.90 |
| PA0440091 | 3530 | 3950 | 907 | 9.55 |
| Ø 64 mm | ||||
| PA0440229 | 1800 | 2220 | 1134 | 7.07 |
| PA0440092 | 2290 | 2710 | 1134 | 7.30 |
| PA0440093 | 2900 | 3320 | 1134 | 9.24 |
| PA0440094 | 3210 | 3630 | 1134 | 10.20 |
| PA0440175 | 3450 | 3870 | 1134 | 10.90 |
| PA0440096 | 3510 | 3930 | 1134 | 11.10 |
| PA0440097 | 4120 | 4540 | 1134 | 13.10 |
| PA0440095 | 4730 | 5150 | 1134 | 15.00 |
| Reference | Description |
| PA0440085 | Wire tong, 38 x 1740 x 2160 mm |
| PA0440086 | Wire tong, 38 x 2200 x 2620 mm |
| PA0440149 | Wire tong, 38 x 2350 x 2770 mm |
| PA0440174 | Wire tong, 38 x 2600 x 3020 mm |
| PA0440087 | Wire tong, 38 x 2960 x 3380 mm |
| PA0440088 | Wire tong, 51 x 1700 x 2120 mm |
| PA0440089 | Wire tong, 51 x 2330 x 2750 mm |
| PA0440226 | Wire tong, 51 x 2400 x 2820 mm |
| PA0440090 | Wire tong, 51 x 2920 x 3340 mm |
| PA0440091 | Wire tong, 51 x 3530 x 3950 mm |
| PA0440229 | Wire tong, 64 x 1800 x 2220 mm |
| PA0440092 | Wire tong, 64 x 2290 x 2710 mm |
| PA0440093 | Wire tong, 64 x 2900 x 3320 mm |
| PA0440094 | Wire tong, 64 x 3210 x 3630 mm |
| PA0440175 | Wire tong, 64 x 3450 x 3870 mm |
| PA0440096 | Wire tong, 64 x 3510 x 3930 mm |
| PA0440097 | Wire tong, 64 x 4120 x 4540 mm |
| PA0440095 | Wire tong, 64 x 4730 x 5150 mm |
| Reference | Dimensions | Working Load (daN) | Approx. Weight (Kg) | |
| Insulated Length (mm) | Overall Length (mm) | |||
| Ø 38 mm | ||||
| PA0440085 | 1740 | 2160 | 680 | 3.30 |
| PA0440086 | 2200 | 2620 | 680 | 4.17 |
| PA0440149 | 2350 | 2770 | 680 | 4.45 |
| PA0440174 | 2600 | 3020 | 680 | 4.93 |
| PA0440087 | 2960 | 3380 | 680 | 5.61 |
| Ø 51 mm | ||||
| PA0440088 | 1700 | 2120 | 907 | 4.60 |
| PA0440089 | 2330 | 2750 | 907 | 6.30 |
| PA0440226 | 2400 | 2820 | 907 | 6.49 |
| PA0440090 | 2920 | 3340 | 907 | 7.90 |
| PA0440091 | 3530 | 3950 | 907 | 9.55 |
| Ø 64 mm | ||||
| PA0440229 | 1800 | 2220 | 1134 | 7.07 |
| PA0440092 | 2290 | 2710 | 1134 | 7.30 |
| PA0440093 | 2900 | 3320 | 1134 | 9.24 |
| PA0440094 | 3210 | 3630 | 1134 | 10.20 |
| PA0440175 | 3450 | 3870 | 1134 | 10.90 |
| PA0440096 | 3510 | 3930 | 1134 | 11.10 |
| PA0440097 | 4120 | 4540 | 1134 | 13.10 |
| PA0440095 | 4730 | 5150 | 1134 | 15.00 |
