Circular Pole Cover
Circular Pole Cover
Circular Pole Cover from TECMARQUES is used for insulating protection during the installation or replacement of poles.
This cover is made of high density polyethylene in orange. It has a polypropylene rope handle to facilitate installation and removal with insulating gloves.
Models
Até Ø 150 mm
Até Ø 230 mm
Até Ø 300 mm
Models
| Reference | Description |
| TM07010101 | Pole cover 150mm x Length 300 mm |
| TM07010102 | Pole cover 150mm x Length 600 mm |
| TM07010201 | Pole cover 230mm x Length 300 mm |
| TM07010202 | Pole cover 230mm x Length 600 mm |
| TM07010203 | Pole cover 230mm x Length 1200 mm |
| TM07010204 | Pole cover 230mm x Length 1800 mm |
| TM07010302 | Pole cover 300mm x Length 600 mm |
| TM07010301 | Pole cover 300mm x Length 300 mm |
| TM07010303 | Pole cover 300mm x Length 1200 mm |
| TM07010304 | Pole cover 300mm x Length 1800 mm |
Até Ø 150 mm
| Reference | Dimensions A (mm) | Dimensions B (mm) | Dimensions C (mm) | Approx. Weight | |
| Kg | lb | ||||
| TM07010101 | 300 | 150 | 115 | 0,70 | 1,54 |
| TM07010102 | 600 | 150 | 115 | 1,20 | 2,65 |
Até Ø 230 mm
| Reference | Dimensions A (mm) | Dimensions B (mm) | Dimensions C (mm) | Approx. Weight | |
| Kg | lb | ||||
| TM07010201 | 300 | 230 | 195 | 1,00 | 2,20 |
| TM07010202 | 600 | 230 | 195 | 1,95 | 4,30 |
| TM07010203 | 1200 | 230 | 195 | 3,95 | 8,71 |
| TM07010204 | 1800 | 230 | 195 | 5,95 | 13,12 |
Até Ø 300 mm
| Reference | Dimensions A (mm) | Dimensions B (mm) | Dimensions C (mm) | Approx. Weight | |
| Kg | lb | ||||
| TM07010302 | 300 | 300 | 115 | 1,15 | 2,54 |
| TM07010301 | 600 | 300 | 115 | 2,35 | 5,18 |
| TM07010303 | 1200 | 300 | 115 | 4,85 | 10,69 |
| TM07010304 | 1800 | 300 | 115 | 7,20 | 15,87 |
