TM0707 - Cobertura isolante para condutor MD (2)

TM0707 - Cobertura isolante para condutor MD (1)

← Back

Rigid Conductor Covers

Name: Rigid Conductor Covers — Tecmarques (EN)
Availability: InStock

Rigid Conductor Covers. The Rigid Conductor Cover from TECMARQUES is manufactured with specific characteristics for construction and maintenance services on energized networks.

Designed for installation by the contact method, its ends are equipped with male/female fitting, which allow firm connections of two or more units.

This cover is made of high density polyethylene.

Optional: This cover can be used with a clip, made of aluminum, which allows its installation on the network by the hot-line method.

Models

Specification

Models

Specification


Reference	Length (mm)	Cable Diameter	Network	Rated Voltage (Phase-to-Phase)	Approx. Weight
					Kg	lb
–	1310	Up to 25 mm	BT	14,6 kV	0.35	0.77
–	1500	Up to 25 mm	AT	14,6 kV	0.90	1.98
TM07070301	1500	Up to 25 mm	AT	26,4 kV	0.90	1.98
TM07070401	1450	Up to 25 mm	AT	36,6 kV	1.60	3.53
	OPTIONAL
TM07070302	Made of aluminum, this clamp is used to allow the installation of the covers on the network by the remote method.				0.15	0.33

Modelo

Reference	Description
–	Rigid conductor cover up to Ø 25 mm BT, 1310 mm, 14,6 kV
–	Rigid conductor cover up to Ø 25 mm AT, 1500 mm, 14,6 kV
TM07070301	Rigid conductor cover up to Ø 25 mm AT, 1500 mm, 26,4 kV
TM07070401	Rigid conductor cover up to Ø 25 mm AT, 1450 mm, 36,6 kV
TM07070302	Clamp for conductor cover

Specification


Reference	Length (mm)	Cable Diameter	Network	Rated Voltage (Phase-to-Phase)	Approx. Weight
					Kg	lb
–	1310	Up to 25 mm	BT	14,6 kV	0.35	0.77
–	1500	Up to 25 mm	AT	14,6 kV	0.90	1.98
TM07070301	1500	Up to 25 mm	AT	26,4 kV	0.90	1.98
TM07070401	1450	Up to 25 mm	AT	36,6 kV	1.60	3.53
	OPTIONAL
TM07070302	Made of aluminum, this clamp is used to allow the installation of the covers on the network by the remote method.				0.15	0.33
