Insulated Scissors
Insulated Scissors
Insulated Scissors from TECMARQUES, has insulated handles made of fiberglass impregnated with epoxy resin and a polyurethane foam core. A tool used to cut AC aluminum (ASC), ACSR (CAA) and copper conductors.
Models
Specification
Models
| Reference | Size |
| TM02130104 | 14″ |
| TM02130101 | 24″ |
| TM02130103 | 30″ |
Specification
| Reference | Size | Diameter | Insulated length | Cutting Capacity (Ø) | Approx. Weight | ||||
| mm | in | mm | in | mm | in | Kg | lb | ||
| TM02130104 | 14″ | 25 | 1″ | 250 | 9-7/8″ | 7,90 | 5/16″ | 1,60 | 3,53 |
| TM02130101 | 24″ | 32 | 1-1/4″ | 500 | 19-3/4″ | 10,11 | 7/16″ | 3,82 | 8,42 |
| TM02130103 | 30″ | 32 | 1-1/4″ | 501 | 19-3/4″ | 12,70 | 1/2″ | 5,85 | 12,90 |
