A Ladder

TM0611 - Escada em A com degraus em fibra de vidro - md

A Ladder

Name: A Ladder — Tecmarques (EN)
Availability: InStock

A Ladder with fiberglass steps is characterized as a natural evolution and replaces wooden ladders with many advantages in the most varied applications.

Models

Specification

Models

Specification


Reference	A (mm)	B (mm)	C (mm)	D (mm)	Number of steps (cada lado)	Approx. Weight
						Kg	lb
TM06110101	1220	550	930	420 x 250	03	15,10	32,29
TM06110102	1510	580	1160	420 x 250	04	18,60	41,00
TM06110103	2130	620	1300	420 x 250	06	25,50	56,22
TM06110104	2730	710	1800	420 x 250	08	32,70	72,09
TM06110105	3350	780	2120	420 x 250	10	40,30	88,84
TM06110106	3960	850	2370	420 x 250	12	48,00	105,82
TM06110107	5170	970	3070	420 x 250	16	64,30	141,76

Modelo

Reference	Description
TM06110101	Double “A” ladder with height of 1220mm, 3 rungs on each side
TM06110102	Double “A” ladder with height of 1510mm, 4 rungs on each side
TM06110103	Double “A” ladder with height of 2130mm, 6 rungs on each side
TM06110104	Double “A” ladder with height of 2730mm, 8 rungs on each side
TM06110105	Double “A” ladder with height of 3350mm, 10 rungs on each side
TM06110106	Double “A” ladder with height of 3960mm, 12 rungs on each side
TM06110107	Double “A” ladder with height of 5170mm, 16 rungs on each side

Specification


Reference	A (mm)	B (mm)	C (mm)	D (mm)	Number of steps (cada lado)	Approx. Weight
						Kg	lb
TM06110101	1220	550	930	420 x 250	03	15,10	32,29
TM06110102	1510	580	1160	420 x 250	04	18,60	41,00
TM06110103	2130	620	1300	420 x 250	06	25,50	56,22
TM06110104	2730	710	1800	420 x 250	08	32,70	72,09
TM06110105	3350	780	2120	420 x 250	10	40,30	88,84
TM06110106	3960	850	2370	420 x 250	12	48,00	105,82
TM06110107	5170	970	3070	420 x 250	16	64,30	141,76
