Twist clamp with eyescrew
Twist clamp with eyescrew
Twist clamp with eyescrew. Twist clamp from TECMARQUES, for high and extra high voltage grounding; aluminum body; smooth jaw; bronze eyescrew type clamping screw; bronze cable plug for plain ferrule
Models
Specification
Models
| Reference | Description |
| TM12070503 | Snap-on (duckbill-type) clamp for high and extra high voltage grounding. |
Specification
| Electrical ratings | |||
| Rated Current (A) | Short-circuit current | ASTM Designation | |
| 400 | 30 Cycles (kA) – 30 | Type – 1 | |
| 60 Cycles (kA) – 23 | Class – A | ||
| Grade – 5 | |||
| Mechanical ratings | |||
| Connection | Cable ferrule (mm²) | Recommended Torque (daN.m) | Approx. Weight (Kg) |
| Maximum – 566 MCM Cu, 900 MCM CAA, Ø 29 mm | Maximum – 95 mm² (4/0 AWG) | 3.0 | 0.72 |
| Minimum – 6 Cu, Ø 4 mm | Minimum – 16 mm² (#2 AWG) | ||
