Temporary Grounding Set for Conventional Secondary Network (LV), with 4 Clamps
Temporary Grounding Set for Conventional Secondary Network (LV), with 4 Clamps
Models
Specification
Models
| Reference | Description |
| TM12020203 | Temporary grounding set for conventional secondary networks (LV), with 5 clamps |
Specification
| Temporary grounding set for conventional secondary network (LV), with 5 clamps |
||||
| Maximum short-circuit current: at 30 cycles: 8 kA; at 60 cycles: 5 kA | ||||
| SET COMPOSITION | ||||
| Item | Reference | Qty | Unit | Description |
| 1 | PI1330007 | 5 | pc | Pressure grounding clamp fixed on Ø 25 mm x 0,30 m stick, with rubber grip |
| 2 | C0450005 | 1.6 | m | Extra flexible copper cable, nominal section 25 mm², with transparent PVC insulation, consisting of 4 lengths of 0,4 m |
| 3 | – | 8 | pc | Tin-plated copper ferrule for cable 25 mm² |
| 4 | – | 8 | pc | Heat shrink |
| 5 | – | 1 | pc | Bag for storage of the set |
