Strap device for crossarm
Strap device for crossarm
Strap device for crossarm is made of galvanized carbon steel. This device is available in two sizes duly manufactured for the coupling of spliced wire tongs, in maintenance work on primary overhead networks, thus allowing the replacement of the wire tong saddle, where the pole space is limited.
Models
Specification
Models
| Reference | Description |
| TM03050301 | Strap device for crossarm – Length 240mm |
| TM03050302 | Strap device for crossarm – Length 140mm |
Specification
| Reference | Diameter (mm) | Length (mm) | Nominal working capacity (daN) | Approx. Weight |
| Kg | ||||
| TM03050301 | 46 | 240 | 454 | 0.66 |
| TM03050302 | 46 | 140 | 454 | 1.16 |
| Reference | Description |
| TM03050301 | Strap device for crossarm – Length 240mm |
| TM03050302 | Strap device for crossarm – Length 140mm |
| Reference | Diameter (mm) | Length (mm) | Nominal working capacity (daN) | Approx. Weight |
| Kg | ||||
| TM03050301 | 46 | 240 | 454 | 0.66 |
| TM03050302 | 46 | 140 | 454 | 1.16 |
